Help with CSS for resizing columns

edit: repro: https://stackblitz.com/edit/tanstack-table-7djbwc?file=src/main.tsx Anyone mind taking a look With this resize in SS #2 you can see the columns sizes are off. The internals are { actions: 1165, firstName: 0, nickName: 817 } but you can see firstName is not the 60px width. Also when i add style={{ width: table.getTotalSize() }} my table doesn't take up w-full like it did before (i believe all the cols are at 120px while the "default" size is 150. When I don't use getTotalSize(), the columns don't adjust (but the code does)

export function DataTable<TData, TValue>({
    columns,
    data,
    initialSearchParams,
}: DataTableProps<TData, TValue>) {

    const table = useReactTable({
        data,
        columns,
        filterFns: {
            fuzzy: fuzzyFilter,
        },
        defaultColumn: {
            minSize: 60,
            maxSize: 800,
        },
        columnResizeMode: 'onChange',

        getCoreRowModel: getCoreRowModel(),
        getFilteredRowModel: getFilteredRowModel(),
        getPaginationRowModel: getPaginationRowModel(),
        onPaginationChange: setPagination,
        onGlobalFilterChange: setGlobalFilter,

        state: {
            pagination: { pageIndex: page - 1, pageSize: count },
            globalFilter,
        },

        initialState: {
            // NavLink sets the initial search params
            pagination: {
                pageIndex: initialSearchParams.page - 1,
                pageSize: initialSearchParams.count,
            },
        },
        debugTable: true,
        debugHeaders: true,
        debugColumns: true,
    })


    const columnSizeVars = useMemo(() => {
        // same as example
    }, [table.getState().columnSizingInfo])

    console.log(globalFilter)
...

export function DataTable<TData, TValue>({
    columns,
    data,
    initialSearchParams,
}: DataTableProps<TData, TValue>) {

    const table = useReactTable({
        data,
        columns,
        filterFns: {
            fuzzy: fuzzyFilter,
        },
        defaultColumn: {
            minSize: 60,
            maxSize: 800,
        },
        columnResizeMode: 'onChange',

        getCoreRowModel: getCoreRowModel(),
        getFilteredRowModel: getFilteredRowModel(),
        getPaginationRowModel: getPaginationRowModel(),
        onPaginationChange: setPagination,
        onGlobalFilterChange: setGlobalFilter,

        state: {
            pagination: { pageIndex: page - 1, pageSize: count },
            globalFilter,
        },

        initialState: {
            // NavLink sets the initial search params
            pagination: {
                pageIndex: initialSearchParams.page - 1,
                pageSize: initialSearchParams.count,
            },
        },
        debugTable: true,
        debugHeaders: true,
        debugColumns: true,
    })


    const columnSizeVars = useMemo(() => {
        // same as example
    }, [table.getState().columnSizingInfo])

    console.log(globalFilter)
...

StackBlitz

Shadcn DataTable Column Resizing Performant Example (forked) - Stac...

Run official live example code for Table Column Resizing Performant, created by Tanstack on StackBlitz

9 Replies

rival-blackOP•2y ago

return (
    <div
        className='flex overflow-auto flex-col p-4 w-full h-full rounded-md border'
    >
        <Table className='' style={{ ...columnSizeVars, width: table.getTotalSize() }}>
            <TableHeader className=''>
                {table.getHeaderGroups().map((headerGroup) => (
                    <TableRow key={headerGroup.id} className=''>
                        {headerGroup.headers.map((header) => {
                            return (
                                <TableHead
                                    key={header.id}
                                    style={{ width: `calc(var(--header-${header.id}-size)))` }}
                                    className='relative border border-zinc-300'
                                >
                                    {header.isPlaceholder
                                        ? null
                                        : flexRender(header.column.columnDef.header, header.getContext())}
                                    <div
                                        onDoubleClick={() => header.column.resetSize()}
                                        onMouseDown={header.getResizeHandler()}
                                        onTouchStart={header.getResizeHandler()}
                                        className={cn(
                                            'hover:bg-red-500 h-12 w-1 absolute top-0 right-0  px-2 cursor-col-resize',
                                            header.column.getIsResizing() ? 'bg-blue-500 ' : '',
                                        )}
                                    />
                                </TableHead>
                            )
                        })}
                    </TableRow>
                ))}
            </TableHeader>

return (
    <div
        className='flex overflow-auto flex-col p-4 w-full h-full rounded-md border'
    >
        <Table className='' style={{ ...columnSizeVars, width: table.getTotalSize() }}>
            <TableHeader className=''>
                {table.getHeaderGroups().map((headerGroup) => (
                    <TableRow key={headerGroup.id} className=''>
                        {headerGroup.headers.map((header) => {
                            return (
                                <TableHead
                                    key={header.id}
                                    style={{ width: `calc(var(--header-${header.id}-size)))` }}
                                    className='relative border border-zinc-300'
                                >
                                    {header.isPlaceholder
                                        ? null
                                        : flexRender(header.column.columnDef.header, header.getContext())}
                                    <div
                                        onDoubleClick={() => header.column.resetSize()}
                                        onMouseDown={header.getResizeHandler()}
                                        onTouchStart={header.getResizeHandler()}
                                        className={cn(
                                            'hover:bg-red-500 h-12 w-1 absolute top-0 right-0  px-2 cursor-col-resize',
                                            header.column.getIsResizing() ? 'bg-blue-500 ' : '',
                                        )}
                                    />
                                </TableHead>
                            )
                        })}
                    </TableRow>
                ))}
            </TableHeader>

<MemoizedTableBody className='overflow-auto'>
                {table.getRowModel().rows?.length ? (
                    table.getRowModel().rows.map((row) => (
                        <TableRow key={row.id} data-state={row.getIsSelected() && 'selected'}>
                            {row.getVisibleCells().map((cell) => (
                                <TableCell
                                    key={cell.id}
                                    className='border border-zinc-300'
                                    style={{ width: `calc(var(--col-${cell.column.id}-size))` }}
                                >
                                    {flexRender(cell.column.columnDef.cell, cell.getContext())}
                                </TableCell>
                            ))}
                        </TableRow>
                    ))
            </MemoizedTableBody>
        </Table>
    </div>
)

<MemoizedTableBody className='overflow-auto'>
                {table.getRowModel().rows?.length ? (
                    table.getRowModel().rows.map((row) => (
                        <TableRow key={row.id} data-state={row.getIsSelected() && 'selected'}>
                            {row.getVisibleCells().map((cell) => (
                                <TableCell
                                    key={cell.id}
                                    className='border border-zinc-300'
                                    style={{ width: `calc(var(--col-${cell.column.id}-size))` }}
                                >
                                    {flexRender(cell.column.columnDef.cell, cell.getContext())}
                                </TableCell>
                            ))}
                        </TableRow>
                    ))
            </MemoizedTableBody>
        </Table>
    </div>
)

@KevinVandy I added a repro https://stackblitz.com/edit/tanstack-table-7djbwc?file=src/main.tsx based on your example https://tanstack.com/table/latest/docs/framework/react/examples/column-resizing-performant Would you mind taking a quick look? You'll notice when you resize a col, it resizes the other columns (but the values in columnSizing don't adjust. I think its maybe a way im applying CSS but not totally sure

national-gold•2y ago

why don't the <th> elements have a width style? You just had a bunch of problems with your table head and table styles Don't delete the * 1px. That's important

rival-blackOP•2y ago

it looks like i had a typo and forgot to pass in 1px , thats one of those problems lol

national-gold•2y ago

got it working

rival-blackOP•2y ago

mind sharing what you did?

national-gold•2y ago

Simply fixed those styles with the proper* 1px calc and correct ending parenthesis Also correct colSpan on the headers

rival-blackOP•2y ago

🙌 thanks! that was what i was missing colSpan={header.colSpan} in TableHead

rival-blackOP•2y ago

With <Table className='overflow-auto' style={{ ...columnSizeVars, width: table.getTotalSize() }}> getTotalSize is setting it to the initial size of all the columns as the default of 150 or 200 as I understand. Do you think the best approach to evenly distribute teh size of the columsn within a parent to use a ref and useeffect to set it on load?

rival-blackOP•2y ago

@KevinVandy actually what prob makes more sense for my usecase is distrbuting only the non-actions/goTo columns across the parent element. I'm trying to do something like this but columnDef = 970px while my logic has the parent width of 1022px.

const columnSizeVars = useMemo(() => {
        const headers = table.getFlatHeaders()
        const fixedColumns = ['goTo', 'actions']
        let fixedColumnsWidth = 0

        const colSizes: { [key: string]: number } = {}

        for (let i = 0; i < headers.length; i++) {
            const header = headers[i]
            if (header && parentTableWrapperRef.current) {
                if (fixedColumns.includes(header.id)) {
                    colSizes[`--header-${header.id}-size`] = header.getSize()
                    colSizes[`--col-${header.column.id}-size`] = header.column.getSize()
                    fixedColumnsWidth += header.getSize()
                }
            }
        }
        console.log(fixedColumnsWidth)

        const parentWidth = parentTableWrapperRef.current?.offsetWidth || 0
        const remainingWidth = parentWidth - fixedColumnsWidth
        const remainingColumns = headers.length - fixedColumns.length
        const remainingColumnWidth = remainingColumns > 0 ? remainingWidth / remainingColumns : 0
        console.log({ parentWidth, remainingWidth, remainingColumns, remainingColumnWidth })
        console.log(remainingColumnWidth * remainingColumns + fixedColumnsWidth)

        for (let i = 0; i < headers.length; i++) {
            const header = headers[i]
            if (header && !fixedColumns.includes(header.id)) {
                colSizes[`--header-${header.id}-size`] = remainingColumnWidth
                colSizes[`--col-${header.column.id}-size`] = remainingColumnWidth
            }
        }
        console.log('Column Sizes:', colSizes)

        return colSizes
    }, [table.getState().columnSizingInfo])

const columnSizeVars = useMemo(() => {
        const headers = table.getFlatHeaders()
        const fixedColumns = ['goTo', 'actions']
        let fixedColumnsWidth = 0

        const colSizes: { [key: string]: number } = {}

        for (let i = 0; i < headers.length; i++) {
            const header = headers[i]
            if (header && parentTableWrapperRef.current) {
                if (fixedColumns.includes(header.id)) {
                    colSizes[`--header-${header.id}-size`] = header.getSize()
                    colSizes[`--col-${header.column.id}-size`] = header.column.getSize()
                    fixedColumnsWidth += header.getSize()
                }
            }
        }
        console.log(fixedColumnsWidth)

        const parentWidth = parentTableWrapperRef.current?.offsetWidth || 0
        const remainingWidth = parentWidth - fixedColumnsWidth
        const remainingColumns = headers.length - fixedColumns.length
        const remainingColumnWidth = remainingColumns > 0 ? remainingWidth / remainingColumns : 0
        console.log({ parentWidth, remainingWidth, remainingColumns, remainingColumnWidth })
        console.log(remainingColumnWidth * remainingColumns + fixedColumnsWidth)

        for (let i = 0; i < headers.length; i++) {
            const header = headers[i]
            if (header && !fixedColumns.includes(header.id)) {
                colSizes[`--header-${header.id}-size`] = remainingColumnWidth
                colSizes[`--col-${header.column.id}-size`] = remainingColumnWidth
            }
        }
        console.log('Column Sizes:', colSizes)

        return colSizes
    }, [table.getState().columnSizingInfo])

Tried this by adding a loading state as well but totalColumnSize is the array that adds up to the 970px instead of the 1022px. Curious to hear if you had a better recommendation

useEffect(() => {
        table.setColumnSizing(columnSizeVars)
        const totalColumnSize = table.getAllColumns().map((c) => c.columnDef?.size)
        console.log(totalColumnSize)
        setLoading(false)
    }, [columnSizeVars, table])

useEffect(() => {
        table.setColumnSizing(columnSizeVars)
        const totalColumnSize = table.getAllColumns().map((c) => c.columnDef?.size)
        console.log(totalColumnSize)
        setLoading(false)
    }, [columnSizeVars, table])
