Receiving incorrect data through Serial

I'm trying to interact with UART using assembly, but I can't seem to get it to print the right data. the main things to look at are putc and puts. everything works fine only if I used one of them and not both in one program.
No description

main.s

5 Replies
wtf
wtfOP•4mo ago
https://pastebin.com/NLFX6HGn
Pastebin
.include "m328pdef.inc" .include "delay.inc" .cseg .or...
Pastebin.com is the number one paste tool since 2002. Pastebin is a website where you can store text online for a set period of time.
WeeGee
WeeGee•3mo ago
putc:
    push        r17

    lds         r17, UCSR0A
    sbrs        r17, UDRE0              ; Wait for empty transmit buffer
    rjmp        putc

    sts         UDR0, r16               ; Transmit byte

    pop         r17
    ret
putc:
    push        r17

    lds         r17, UCSR0A
    sbrs        r17, UDRE0              ; Wait for empty transmit buffer
    rjmp        putc

    sts         UDR0, r16               ; Transmit byte

    pop         r17
    ret
Looks like this is going to blow up your stack as you wait. Every time you wait here, you're going back to putc and re-pushing r17 to the stack would also make sense why you're only getting issues when you try to use both putc AND puts; I assume puts calls putc my suggestion would be this
putc:
    push        r17
putc_waitloop:
    lds         r17, UCSR0A
    sbrs        r17, UDRE0              ; Wait for empty transmit buffer
    rjmp        putc_waitloop              ;jump to AFTER preserving r17

    sts         UDR0, r16               ; Transmit byte

    pop         r17
    ret
putc:
    push        r17
putc_waitloop:
    lds         r17, UCSR0A
    sbrs        r17, UDRE0              ; Wait for empty transmit buffer
    rjmp        putc_waitloop              ;jump to AFTER preserving r17

    sts         UDR0, r16               ; Transmit byte

    pop         r17
    ret
note though that I haven't checked your code very far; this was the first thing that stuck out to me so idk if this is the root of the issue @wtf so just checked for clarification; you're NOT using putc to help implement puts for some reason; I'd suggest using the putc that's in puts to re-make putc, then have puts call putc seems that puts's character printing is at least somewhat working for printing Hello
wtf
wtfOP•3mo ago
that's so obvious idk how I didn't catch that I'll give it a shot works there goes 1 day of debugging to a dumb mistake
WeeGee
WeeGee•3mo ago
This is why things are typically broken down into parts like this; the whole point of making putc is so you only have to debug "print a single character to serial" once, then you write "print a string" in terms of "print a single character" and loops/conditionals I'd strongly suggest making your puts call putc so you don't have two separate snippets of code that print to serial (that's 2x the places for you to make such a hard to spot mistake)
wtf
wtfOP•3mo ago
that's what I did. will keep that in mind for the future
