DEVHEADS DEMO: How to Implement Finite State Machines in FPGA Fabric

FPGAs are among the most versatile technologies available on the market today, but capitalizing on that versatility means learning hardware description languages like VHDL or Verilog, different requirements in terms of board design and routing, and how all of that impacts software development.

But don't knock it before you try it. In this Demo, @Navadeep shows us how to implement synchronous and asynchronous finite state machines In FPGA fabric using the Verilog HDL. The demo uses an AMD Zynq 7020, but the Verilog code is available on the DevHeads GitHub and can be adapted for other FPGA targets as well.

If you're an @MCU, MPU & Kits developer and are looking to get up to speed on FPGA programming, start here.

https://youtu.be/E5sQu90UeII

YouTubeDevHeads

How to Implement Finite State Machines on AMD Xilinx Zynq 7020 FPGA

All it takes is one word and four letters to make most developers zone out: F-P-G-A.

FPGAs are among the most versatile technologies available on the market today, but capitalizing on that versatility means learning hardware description languages like VHDL or Verilog, different requirements in terms of board design and routing, and how all of t...
