as a practical example: should we add a sendN2K(pgn: PGN) to the plugin API to make use of the pgn types? timetimestamp is not optional in PGN, but if I construct a message to be sent i would not assign that. likewise source. should there be separate types for an abstract "PGNData" object, with just the data fields, and another AddressedPGN with source and dest and third for ReceivedPGN? or just make the addresses and timestamp optional? the one pgns.ts to rule them all file is a bit unwieldy, how about breaking the enums to enums.ts?

Teppo Kurki•2mo ago

the enums are now compiler-checked constants that map to string values that you can use when constructing PGNs. what about the other way, when decoding? If i had some received pgn data and wanted to do a lookup on same lookup field value, like tank type with value 1 the current enums are no help typescript has also Numeric Enums that provide Reverse Mappings: from numeric value to the name of the enum value ...or is canboatjs going to taking care of all this, parsing and encoding, and code outside canboatjs only deals with PGN objects, not the raw data? numeric lookups can also wait until somebody needs them, just pointing out that one could leverage ts enums in this

Handbook - Enums

How TypeScript enums work

Teppo Kurki•2mo ago

have you tried converting n2k-signalk or sk-to-n2k to ts using these? or something else, like autopilot plugin

Scott BenderOP•2mo ago

Yes, canboatjs deals with that, the enums are strings coming out of canboatjs. (always have been) yes! I've done the initial pass of converting canboatjs to typescript, going to start on n2k-signalk today... I think I I think I'll just make those optional

Scott BenderOP•2mo ago

start of n2k-signal conversion https://github.com/SignalK/n2k-signalk/pull/287

GitHub

WIP convert to canboatjs typescript by sbender9 · Pull Request #28...

Teppo Kurki•2mo ago

All the PGN_xxxFields’ properties are optional. Doesn’t that make them less valuable, as the structure of the object can be kind of anything?

Scott BenderOP•2mo ago

well, you still get type checking and not all of them are, if they are "PartOfOrimaryKey", then not optional other than that, we don't really know if they are optional or not, but most fields are optional a recent change is tha now all the enum fields can be a number., pilotMode?: enums.SeatalkPilotMode16|number for example this is because it's possible that something comes in that is not in the lookup don't love it, but don't know of any other way to deal with it (just made fields that are only 1 bit, not optional)

Scott BenderOP•2mo ago

FYI. pgns moved to https://github.com/canboat/ts-pgns

GitHub

GitHub - canboat/ts-pgns: TypeScript Canboat PGN Definitions

TypeScript Canboat PGN Definitions. Contribute to canboat/ts-pgns development by creating an account on GitHub.

Scott BenderOP•2mo ago

canboatjs now conerted to typescript

GitHub

WIP feature: update to ts based pgns by sbender9 · Pull Request #3...

Scott BenderOP•2mo ago

also of interest, a workflow that tests canboat.json changes with canboatjs, n2k-signalk and signalk-nmea2000, this will eventually get triggered any time canboat.json changes in the canboat repository https://github.com/canboat/canboatjs/blob/ts-pgns/.github/workflows/test_canboat_changes.yml

GitHub

canboatjs/.github/workflows/test_canboat_changes.yml at ts-pgns · ...

Native javascript NMEA 2000 decoder and encoder. Contribute to canboat/canboatjs development by creating an account on GitHub.

Scott BenderOP•2mo ago

signalk-to-nmea2000 converted to ts https://github.com/SignalK/signalk-to-nmea2000/pull/128

GitHub

WIP feature: convert to typescript by sbender9 · Pull Request #128...

Scott BenderOP•2mo ago

And note that I have released canboatjs 3.1.x which uses the new ts-pgns package. @Teppo Kurki this brings up an issue that I can’t find a great solution for. The new sk-to-n2k (and eventually others), won’t work with older versions of the server. This is because of the use of camelCase keys. The best I can come up with is to have the plugin check the server version and refuse to start with an error message on the console. Going forward, it would be great to have a way for plugins to specify min server version. Sadly, I don't see any way to add extra meta data to the info coming from npmjs.com. So, the only things I can think of: 1. Use keywords, so a plugin could add a keyword like signalk-server-min-version-1.15.x 2. We have talked about moving away from npmjs.com and creating our own plugin registry. Unless anyone has a better solution or wants to work on #2, I'll probably go ahead and implement #1

Teppo Kurki•2mo ago

1. would mean removing the generic plugin keyword, or people with older servers would update the plugin to a nonfunctioning one 3. create sk-to-n2k-v2 with separate plugin id and the way you said, prompts people with older servers to upgrade. Then plugin updates won’t break people’s systems. Publish one more version of the old series that also prompts people to update to v2. Bootstrap v2 settings from v1 Is mapping from old keys to camelCase ones not feasible?

Scott BenderOP•2mo ago

yeah, I was just thinking about that, or the other way around. I could map the camelCase keys to the old keys when running on an older server canboatjs support both as input, so existing plugins that output N2K won't be broken and by default, canboatjs outputs both camelCase and the old keys, so existing plugins/node-red flows won't be broken (currently there is a switch in the admin-ui to turn that off) I think I'll add a utility function in ts-pgns that maps from camelCase keys to the old keys, sk-to-n2k and other plugins can use that to support old versions of the server For you typescript gurus, I am thinking there is probably a cooler way to do this. Currently this is how you create pgn to be send out.

const pgn: PGN_61184_VictronBatteryRegister = {
  ...PGN_61184_VictronBatteryRegisterDefaults,
  fields: {
    ...PGN_61184_VictronBatteryRegisterMatchFields,
    registerId: 1,
    payload: 100
   }
}

const pgn: PGN_61184_VictronBatteryRegister = {
  ...PGN_61184_VictronBatteryRegisterDefaults,
  fields: {
    ...PGN_61184_VictronBatteryRegisterMatchFields,
    registerId: 1,
    payload: 100
   }
}

` Any ideas on a more elegant way? I think this is better?

const battery = create61184_VictronBatteryRegister({
  registerId: 1,
  payload: 100
})

const battery = create61184_VictronBatteryRegister({
  registerId: 1,
  payload: 100
})

And the result looks like:

{
  pgn: 61184,
  dst: 255,
  prio: 3,
  fields: {
    manufacturerCode: 'Victron Energy',
    industryCode: 'Marine',
    registerId: 1,
    payload: 100
  }
}

{
  pgn: 61184,
  dst: 255,
  prio: 3,
  fields: {
    manufacturerCode: 'Victron Energy',
    industryCode: 'Marine',
    registerId: 1,
    payload: 100
  }
}
