Such an RF path can be designed easily. The issue is such an RF path must be evaluated with expensive RF instruments later. The task is simple. You need two impedance-matching networks (one at the transceiver output and the second at the antenna feeder) and a transmission line. For both networks, there are recommended designs by the transceiver manufacturers. For the transmission line, there are calculators on the Internet. To design such an RF path is not rocket science. Making it correctly involves prototype evaluation and measurement. The tutorial would be a longer format than a 3-5 minute demo.
