Cannot get VAOC to run.

Hi, I added the configuration like mentioned but I am getting no camera image. In raspi I tried

libcamera-hello --list-cameras

libcamera-hello --list-cameras

which tells me there are no camera available.

This is the dmesg output

[ 1119.585464] usb 1-1.1.3: Found UVC 1.00 device Rat Rig VAOC Camera (1bcf:28c6)
[ 1119.624707] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 5 on unit 2: -32 (exp. 1).
[ 1119.639673] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 3 on unit 1: -32 (exp. 1).
[ 1119.650594] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 5 on unit 1: -32 (exp. 1).
[ 1119.661377] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 7 on unit 1: -32 (exp. 1).
[ 1119.668048] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 10 on unit 1: -32 (exp. 1).
[ 1119.682930] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 14 on unit 1: -32 (exp. 1).
[ 1119.693692] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 16 on unit 1: -32 (exp. 1).
[ 1119.721327] input: Rat Rig VAOC Camera: Rat Rig VA as /devices/platform/scb/fd500000.pcie/pci0000:00/0000:00:00.0/0000:01:00.0/usb1/1-1/1-1.1/1-1.1.3/1-1.1.3:1.0/input/input2
[ 1120.207209] usb 1-1.1.3: 3:1: cannot get freq at ep 0x86
[ 1120.209890] usb 1-1.1.3: 3:2: cannot set freq 11025 to ep 0x86
[ 1120.211726] usb 1-1.1.3: 3:3: cannot set freq 16000 to ep 0x86
[ 1120.689016] usb 1-1.1.3: 3:4: cannot get freq at ep 0x86
[ 1120.691700] usb 1-1.1.3: 3:5: cannot set freq 24000 to ep 0x86
[ 1120.693603] usb 1-1.1.3: 3:6: cannot set freq 32000 to ep 0x86
[ 1121.170789] usb 1-1.1.3: 3:7: cannot get freq at ep 0x86
[ 1121.173449] usb 1-1.1.3: 3:8: cannot set freq 48000 to ep 0x86
[ 1121.216908] usb 1-1.1.3: Warning! Unlikely big volume range (=4096), cval->res is probably wrong.
[ 1121.216932] usb 1-1.1.3: [7] FU [Mic Capture Volume] ch = 1, val = 0/4096/1

[ 1119.585464] usb 1-1.1.3: Found UVC 1.00 device Rat Rig VAOC Camera (1bcf:28c6)
[ 1119.624707] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 5 on unit 2: -32 (exp. 1).
[ 1119.639673] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 3 on unit 1: -32 (exp. 1).
[ 1119.650594] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 5 on unit 1: -32 (exp. 1).
[ 1119.661377] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 7 on unit 1: -32 (exp. 1).
[ 1119.668048] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 10 on unit 1: -32 (exp. 1).
[ 1119.682930] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 14 on unit 1: -32 (exp. 1).
[ 1119.693692] usb 1-1.1.3: Failed to query (GET_INFO) UVC control 16 on unit 1: -32 (exp. 1).
[ 1119.721327] input: Rat Rig VAOC Camera: Rat Rig VA as /devices/platform/scb/fd500000.pcie/pci0000:00/0000:00:00.0/0000:01:00.0/usb1/1-1/1-1.1/1-1.1.3/1-1.1.3:1.0/input/input2
[ 1120.207209] usb 1-1.1.3: 3:1: cannot get freq at ep 0x86
[ 1120.209890] usb 1-1.1.3: 3:2: cannot set freq 11025 to ep 0x86
[ 1120.211726] usb 1-1.1.3: 3:3: cannot set freq 16000 to ep 0x86
[ 1120.689016] usb 1-1.1.3: 3:4: cannot get freq at ep 0x86
[ 1120.691700] usb 1-1.1.3: 3:5: cannot set freq 24000 to ep 0x86
[ 1120.693603] usb 1-1.1.3: 3:6: cannot set freq 32000 to ep 0x86
[ 1121.170789] usb 1-1.1.3: 3:7: cannot get freq at ep 0x86
[ 1121.173449] usb 1-1.1.3: 3:8: cannot set freq 48000 to ep 0x86
[ 1121.216908] usb 1-1.1.3: Warning! Unlikely big volume range (=4096), cval->res is probably wrong.
[ 1121.216932] usb 1-1.1.3: [7] FU [Mic Capture Volume] ch = 1, val = 0/4096/1

Solution

Ok I got the config from the git page (https://github.com/VisualTech48/RatOS/blob/patch-1/site/docs/VAOC.md) and removed the custom_flags in the config and it worked. One issue was that the flat cable was mounted in the wrong direction. (The one in Step 18) Also it seems like the usb cable was a little loose, so I changed the usb port. Thanks for your help.

GitHub

RatOS/site/docs/VAOC.md at patch-1 · VisualTech48/RatOS

The preconfigured Raspberry Pi image that makes it easy to run Klipper + Moonraker + Mainsail on your printer. - VisualTech48/RatOS
