Current state of a force feedback pedal set in slow building. Using the pendicular f-14 design. Woul

Current state of a force feedback pedal set in slow building. Using the pendicular f-14 design. Would your software work in this application or would it require modification?

walmis•5/19/22, 8:02 PM

Yeah I think so. The SW/FW is quite versatile.

walmis•5/19/22, 8:06 PM

But man, that looks heavy :)

ARMORINE | Silver 1-2OP•5/19/22, 8:07 PM

It’s very heavy. Will be around 70 lbs when completed. I got tired of chasing my current pedal set across the floor. This sucker could be a boat anchor

AARMORINE | Silver 1-2 It’s very heavy. Will be around 70 lbs when completed. I got tired of chasing my...

Otto•5/19/22, 8:41 PM

Looks like it'll help hold the pallet jack.

AARMORINE | Silver 1-2 Current state of a force feedback pedal set in slow building. Using the pendicul...

Gator•5/19/22, 8:44 PM

Sim controls that need welding are GTG in my book!

ARMORINE | Silver 1-2OP•5/19/22, 8:45 PM

Half inch steel plate don’t mess around

walmis•5/19/22, 8:47 PM

GTG - good to go?

Wwalmis GTG - good to go?

Gator•5/19/22, 8:47 PM

Yes.

AARMORINE | Silver 1-2 It’s very heavy. Will be around 70 lbs when completed. I got tired of chasing my...

mechsicko•5/20/22, 2:45 AM

Why not make them normal weight and just mount them to something?

ARMORINE | Silver 1-2OP•5/20/22, 2:54 AM

https://tenor.com/view/camp-nowhere-christopher-lloyd-smart-act-stupid-advice-gif-18470735

Tenor

ARMORINE | Silver 1-2OP•5/20/22, 2:55 AM

Any time I post ANY THING remember the above

ARMORINE | Silver 1-2OP•5/20/22, 2:56 AM

Also in my defense. I wasn’t planning on building a full sim rig when I started this….then a friend gifted me a rig

ARMORINE | Silver 1-2OP•5/20/22, 2:58 AM

Now I have this monstrosity

Flashgod_VR•5/20/22, 1:32 PM

@nibbylot

nibbylot•5/20/22, 1:54 PM

This looks interesting, I’ve been looking to get a ffb sick for awhile

Flashgod_VR•5/20/22, 2:07 PM

my search ended here...

Flashgod_VR•5/20/22, 2:08 PM

and it took more than a decade

Vulkan•5/20/22, 2:18 PM

Does the sticking coming soon have a sustained force limit?. And what's it max momentary force

walmis•5/20/22, 2:21 PM

The motors do heat up at max force, but with active cooling it's not a big problem like in the Brunner. The peak force for the 'Rhino' base is around 5Nm.

Vulkan•5/20/22, 4:44 PM

Awesome! Is it available for purchase yet? I heard a rough price of 800. I just be interested in the process of doing it. And some more information of the stick itself. I've been going through the channels here but I'm finding it hard to get a clear of it.

walmis•5/20/22, 6:08 PM

You can preorder a unit at the moment, I'm currently building a batch of 6 Rhinos. The price is 800€ for the finished base. Could you elaborate on what you mean "process of doing it"? Are you interested in the ordering process or building a joystick base yourself using a motor kit? :) I'm still working on the website, information and e-shop will be there in one place once that's taken care of :) You can freely ask any questions for more info about the Rhino base.

Wwalmis You can preorder a unit at the moment, I'm currently building a batch of 6 Rhino...

Vulkan•5/20/22, 7:02 PM

Oh I mean how one orders, like how long it would take for a batch to be ready and costs of shipping, I'm in AUS. I don't think I'm quite that talented yet to make my own.

Vulkan•5/20/22, 7:08 PM

More over about the base its self why do you think its the best on the market? What does it do compared which the others don't. How long is the warranty and will repairing it myself void it?

Kapti•5/20/22, 7:12 PM

Ill chime in real quick. A friend just ordered motors for a base we are working on and they just came in yesterday. The software for these motors is amazing. The amount of adjustability and features is awesome. I would expect to see this come out of a huge corporation with a big budget. Great job Walmis!

Wwalmis You can preorder a unit at the moment, I'm currently building a batch of 6 Rhino...

Right Rudder - Left Stick•5/20/22, 7:27 PM

What would the motor kit include? I have most of a printed propeler style gimbal but have it in pieces as I've refocused on other stuff? I guess I'd need to print a fresh gimbal?

RRight Rudder - Left Stick What would the motor kit include? I have most of a printed propeler style gimbal...

walmis•5/20/22, 7:38 PM

You can use that gimbal! The motor kit provides two motors, wires to hook everything up and an FFB USB controller. It's a plug and play system, you only need to do basic calibration to get it running.

VVulkan More over about the base its self why do you think its the best on the market? W...

walmis•5/20/22, 7:39 PM

I'll get back to you tomorrow :)

Right Rudder - Left Stick•5/20/22, 10:26 PM

do the motor kits include the hall effect sensors too?

Kapti•5/20/22, 10:48 PM

No need. The position is direct from the motors.

Wwalmis You can preorder a unit at the moment, I'm currently building a batch of 6 Rhino...

sko•5/21/22, 1:54 AM

Id like to preorder a fully built unit. let me know what i need to do.

KKapti Ill chime in real quick. A friend just ordered motors for a base we are working ...

Flashgod_VR•5/21/22, 5:05 AM

I also can chime in here. Walmis accomplished something on such a high quality standard on his own, where usually much bigger teams with higher count of individual professionals are needed. I was already extremely curious by the information he shared about the details, everything made sense "on paper" instantly. And after finally getting my hands on the Rhino, i was simply blown away.

FFlashgod_VR I also can chime in here. Walmis accomplished something on such a high quality s...

Otto•5/21/22, 5:14 AM

Both @.kapti. and I experienced the same. This truly is a giant leap forward into the simulation experience for the community. Hoping to make it affordable for many to enjoy.

Flashgod_VR•5/21/22, 8:28 AM

@everyone just wrote my first thoughts about the Rhino in the DCS FFB thread. some of you may find certain answers for your questions there: https://forum.dcs.world/topic/246873-honey-i-developed-ffb-joystick-diy/?do=findComment&comment=4973130

ED Forums

Honey, I developed FFB joystick (DIY)

Ssko Id like to preorder a fully built unit. let me know what i need to do.

walmis•5/21/22, 3:22 PM

You can DM me - Currently I take orders by creating an invoice through PayPal. For the Rhino I'll take a small deposit to confirm the order, and once it's ready before shipping we'll finish the transaction.

Fer•5/21/22, 6:46 PM

Hel @walmis what’s the cost, does it use winwing and virpil sticks ??

walmis•5/21/22, 7:01 PM

Hi @fer4705 , the price for the complete base is 800EUR, Virpil is supported (T50CM2 - fully tested, others will follow), WinWing adapter will be developed later.

walmis•5/21/22, 7:02 PM

You can also read the great review by @flashgod_vr here: https://forum.dcs.world/topic/246873-honey-i-developed-ffb-joystick-diy/page/17/#comment-4973130

ED Forums

Honey, I developed FFB joystick (DIY)

Fer•5/21/22, 8:27 PM

Thanks @walmis

f4l0•5/22/22, 5:35 AM

Hey @walmis ,

I'm the developer of SimShaker for Aviators, @flashgod_vr ask me to get in touch with you to discuss the possibilities to enhance the FFB experience with SSA data, or to help you, to get data from DCS...
