Also along those lines is there anybody that has or can share their personal setups for different operations, such as helicopters, warbirds, jets, etc.?

DoctaGriff•12/2/24, 12:18 AM

What do you guys do to keep the stick from slamming around when you crash? Sometimes it faults the encoder and I have to restart the FFB.

DDoctaGriff What do you guys do to keep the stick from slamming around when you crash? Somet...

f14billy•12/2/24, 12:44 AM

If you add some damper it may help with that.

AAndre Also along those lines is there anybody that has or can share their personal set...

f14billy•12/2/24, 12:45 AM

📙knowledge-baseRhino Profile Sharing

f14billy•12/2/24, 12:45 AM

That may help you

AndreOP•12/2/24, 1:51 AM

Thanks!

AndreOP•12/2/24, 1:51 AM

might be a stupid question, but how do I open up this page on the configurator?

AAndre might be a stupid question, but how do I open up this page on the configurator?

TheAmazinGreat•12/2/24, 2:19 AM

That is TelemFFB. It is a separate program that helps manage aircraft and sim specific effects based on telemetry outputs from the sim.

AAndre the amount of settings in the configurator is kind of overwhelming to be honest ...

TheAmazinGreat•12/2/24, 2:27 AM

Check the knowledge base section for the manual. This is also a quick way to get started: 📃general

The basics are: effects tab and settings tabs are multipliers of each other so 50% spring in effects and 50% spring on settings will be 25% final setting.

Start with 100% in effects tab and 0% in settings and tune up on settings tab to desired effect. Best to do spring last as mentioned in the linked post above.

Friction and inertia at high settings can cause instability so don’t put more in than you need.

There are two tabs because the sim can (but doesn’t always) override the effect %. I think most, if not all, sims will only override spring. So your other effects, if not overridden by the sim, will remain as is.

AndreOP•12/2/24, 4:25 AM

ah gotcha. Thanks!

Trinity•12/2/24, 6:55 AM

Anyone here mount the Rhino to the Monstertech flight chair? Got mine put together today and am running into constant issues with the Rhino mount

DDoctaGriff What do you guys do to keep the stick from slamming around when you crash? Somet...

Touch_Of_Legend•12/2/24, 9:47 AM

Before you crash hit the Oh shit button!

Err I mean E stop

Touch_Of_Legend•12/2/24, 9:52 AM

Touch_Of_Legend•12/2/24, 9:52 AM

So first you pull this and then you smash the E stop

DDoctaGriff What do you guys do to keep the stick from slamming around when you crash? Somet...

Hiob•12/2/24, 12:28 PM

Reduce the effect intensity/gain for the deceleration! Or the constant force gain in VP config.

Hiob•12/2/24, 12:33 PM

@Number481 I don't now the values from the top of my head, but maybe the default gain for decel. should be a bit lower....... You know, protect poeple from themselves.

(....or protect the Rhino from the sim...

)

VPforceBot•12/2/24, 1:13 PM

:package:

RHINO #0810 Has Shipped!

VPforceBot•12/2/24, 1:13 PM

:package:

RHINO #0809 Has Shipped!

TTrinity Anyone here mount the Rhino to the Monstertech flight chair? Got mine put togeth...

Dracks•12/2/24, 5:11 PM

Yeah in the past a
I had this (now I have a MTS frame but globally similar). How can I help ?

Mayo•12/3/24, 4:46 AM

Hello guys
How long would shipping go, when I order 4?

amadeus•12/3/24, 4:47 AM

shipping is generally in about 2-3 weeks tops depending on where you are in the world, the bigger issue is the waitlist which if you sign up now, will take a bit

Mayo•12/3/24, 4:48 AM

How long should I expect?

smitty•12/3/24, 5:04 AM

!status

Ssmitty !status

VPforceBot•12/3/24, 5:04 AM

Hey @smitty,
So the last Shipped RHINO is #0809 on 2024-12-02
Average waiting time from preorder to shipped is 209 days, median is 210 days, max is 437 days
773 Rhinos are shipped in total

DDracks Yeah in the past a I had this (now I have a MTS frame but globally similar). How...

Trinity•12/3/24, 5:23 AM

Sorry, went to reply to this a few times but the day got away from me. Looks like the documentation I was using was outdated or something. Using the correct screws helps. Just got it mounted and am happy with the way it looks at first. Did you have any degredation issues or problems with the bolts loosening? Or was it pretty solid during your time using it?

TTrinity Sorry, went to reply to this a few times but the day got away from me. Looks lik...

Dracks•12/3/24, 5:54 AM

Don't worry, there's plenty of time to answer

.

I had no trouble mounting it. I had taken the MTS support for the Rhino and no problems after the first few uses. Now I've had the Rhino for 7 months and it's holding perfectly. I'm sure I'll have to tighten the screws in a few months, but everything's holding! I've put some photos in the "showcase" sub-section, so you should be able to find them easily.

MMayo How long should I expect?

Hiob•12/3/24, 7:31 AM

Better to ask @walmis for the current lead times. I have the feeling that the stats stated by the bot are not that relevant anymore. (and of course you can have one much faster as a DIY-kit)

walmis•12/3/24, 7:40 AM

Currently approx 90 days

Hiob•12/3/24, 10:49 AM

that sounds much better, doesnt it?

Mayo•12/3/24, 11:36 AM

Yeeess haha

VPforceBot•12/3/24, 1:34 PM

:package:

RHINO #0811 Has Shipped!

VPforceBot•12/3/24, 1:34 PM

:package:

RHINO #0813 Has Shipped!

VPforceBot•12/3/24, 1:34 PM

:package:

RHINO #0814 Has Shipped!

VPforceBot•12/3/24, 1:34 PM

:package:

RHINO #0815 Has Shipped!

Parabe11um•12/3/24, 2:18 PM

Hello, with my order number coming up, I have some questions so I can plan.

I am currently running a 200 mm extension for my VKB MCGU, I like it a lot, so would prob prefer a similar feel.

Does anyone have experience or ideas in terms of extension needed for the Rhino for something similar? I've heard some people say extensions are not required.

I've been looking for an excuse to try the WW F-16EX grip, provided an adapter is used does it work well with the Rhino (e.g., any missing buttons or axis)? Also any thoughts on extensions for the F-16EX grip?

PParabe11um Hello, with my order number coming up, I have some questions so I can plan. I a...

Hiob•12/3/24, 2:21 PM

The Rhino has quite a long lever to the connection thread per default. To equalize with your current throw length a 10mm extension will probably be sufficiant. In the knowledge base you find technical drawings were those measures are laid out.

Hiob•12/3/24, 2:21 PM

https://discord.com/channels/965234441511383080/1118790519103967242

HHiob The Rhino has quite a long lever to the connection thread per default. To equali...

Parabe11um•12/3/24, 4:09 PM

Got it, I found a lot of previous discussion on it too and it seems like a general consensus is no extension or 10 cm

Parabe11um•12/3/24, 4:09 PM

Do you have any experience with offset (e.g., extension offset to increase distance between base and grip)?

PParabe11um Got it, I found a lot of previous discussion on it too and it seems like a gener...

Hiob•12/3/24, 4:10 PM

That doesn't mean though that 20cm doesn't work. A lot of people (me included) use a 20cm gooseneck extension.

Parabe11um•12/3/24, 4:10 PM

Yeah, fair

PParabe11um Do you have any experience with offset (e.g., extension offset to increase dista...

Hiob•12/3/24, 4:10 PM

Offset is no problem. There are plenty of options to balance an offset or heavy grip.

Trinity•12/3/24, 8:43 PM

Is there somewhere I could obtain an STL for printing pulley covers?

TTrinity Is there somewhere I could obtain an STL for printing pulley covers?

kaltokri•12/3/24, 9:15 PM

Here: https://discord.com/channels/965234441511383080/1212035455764144209/1254433615220310038

Kkaltokri Here: https://discord.com/channels/965234441511383080/1212035455764144209/125443...

Trinity•12/3/24, 9:37 PM

Thanks! Should help increase the odds of the kid growing up with all his pieces lol

Trinity•12/4/24, 12:54 AM

Do these screw down? Not seeing where it's supposed to attach

Reed•12/4/24, 2:21 AM

When using balance spring are you all balancing in all 4 quadrants or extremes of each axis or just so it stays centered in the middle.

907basebal•12/4/24, 2:27 AM

Hi, I’ve got two questions, does the base work with Tianhang sticks, and what the current wait time?

RReed When using balance spring are you all balancing in all 4 quadrants or extremes o...

TheAmazinGreat•12/4/24, 3:27 AM

The goal is that with all effects off you can move the stick to any position and it holds there. You can also play with the "static force" setting to achieve the desired effect. I ended up not needing any balance spring, but just a bit of static force. It all depends on your setup.

TTouch_Of_Legend Click to see attachment

Ry-ballz•12/4/24, 3:46 AM

Did you make that?

RReed When using balance spring are you all balancing in all 4 quadrants or extremes o...

Hiob•12/4/24, 6:42 AM

In fact, I would start with the static force if any balancing is needed.
My Approach is this. Turn off all effects and center the stick dead on the middle of the grid. If it drops significantly in any direction, apply static force until it doesn't.
Now place the stick to the second to last corner on the grid. First north than south than west than east than nw, ne, sw, se. Etc. The stick should drop in the direction you put it with the same "speed". If not tune the static force accordingly.
If you have difficulties balancing or a very long extension/ heavy grip, you may add some friction before starting the process.
After that you can add some balancing spring.
