Hi @walmis literally just got the email saying my order is ready! Very exciting news but before I pu

Hi @walmis literally just got the email saying my order is ready! Very exciting news but before I pull the trigger, 2 questions: 1) can this be mounted in the NLR Boeing sim seat? That is my set up along with 2) is it compatible with WinWing sticks? If so, consider it sold mate! Cheers

KKnuck👨✈Hi @walmis literally just got the email saying my order is ready! Very exciting ...

walmis•2/13/24, 11:01 AM

2) yes, you can grab the WinWing adapter during ordering.
1) Likely yes (with some tinkering), but I suggest searching this Discord, maybe someone has mounted his on that seat.

VPforceBot•2/13/24, 11:08 AM

:package:

RHINO #0398 Has Shipped!

VPforceBot•2/13/24, 11:48 AM

:package:

RHINO #0399 Has Shipped!

SSR-F Wofei Hi guys, anyone wo has mounted the rhino on a next next level flightsim seat out...

Stains•2/13/24, 1:35 PM

I got a piece of plywood the size of the NLR seat footprint and mounted my Rhino to the floor.

Mmark turner Hi fellas, ( or girls) does anyone here have a profile for the AV8BNA Harrier th...

Boggy•2/13/24, 2:12 PM

I mainly fly the Harrier and have kept just the standard profile but I did add end stops at 90ish %. I have also reduced the max amount of deflection needed for roll because I have a VR pit and it will interfere with my nozzle lever and leg.

Chuff•2/13/24, 6:37 PM

the default connector that comes on the unit fits TM sticks with no adaptor, correct?

Stryker990•2/13/24, 6:51 PM

@Bird*dog could u give me pointer on how you build that distanceholder for your chair with the rudderpedal? got MFG crosswind myself and having something like that would be great (reference to https://discord.com/channels/965234441511383080/1000639415208656926/1203901633717870652)

Discord

Discord - A New Way to Chat with Friends & Communities

Discord is the easiest way to communicate over voice, video, and text. Chat, hang out, and stay close with your friends and communities.

Ada-Chan!•2/13/24, 6:54 PM

sorry if wrong channel - am i required to make the purchase when my turn comes around? like if something happened and i suddenly can't afford it, what's my recourse?

AAda-Chan!sorry if wrong channel - am i required to make the purchase when my turn comes a...

PiNKSH!T•2/13/24, 6:55 PM

talk to walmis about that, I'm sure if it's only a short term thing he might accommodate. You will have a decent amount of time to save & you should get a good idea when your number will be coming up, you could always ask someone to swap out with a lter spot in the line?

Ada-Chan!•2/13/24, 6:56 PM

got it, ok. just didn't want to cause any inconvenience for anyone if a sudden expense came up

walmis•2/13/24, 6:57 PM

Yeah, no worries, you can cancel it when your spot comes up

Ada-Chan!•2/13/24, 6:57 PM

thanks!

Stryker990•2/13/24, 7:01 PM

i would normally say yes cancel (so i can get mine earlier) but i would assume ur after me anyway

SStryker990 @Bird*dog could u give me pointer on how you build that distanceholder for your ...

Bird*dog•2/13/24, 7:29 PM

I actually got them off of Amazon a few years ago. They don’t seem to be in stock very often though, but you might have some luck getting them direct from the manufacturer: https://www.peingear.com/product-page/pein-s-pedal-mount

PEIN Gear Mount

PEIN Pedal Mount (Upgrade) Free shipping worldwide. | PEIN Gear Mount

Introduction to PEIN Pedal MountThe PEIN Pedal Mount is designed to hold racing wheel pedals in car games securely and rudder pedals in airplane games. An essential tool for gamers looking to enhance their gaming experience by providing a stable and precise platform for their pedals. Durable Construction and Features of PEIN Pedal MountPEIN peda...

BBird*dog I actually got them off of Amazon a few years ago. They don’t seem to be in stoc...

Stryker990•2/13/24, 7:49 PM

thx

Leddhedd•2/13/24, 7:49 PM

i had a quick question, if anyone happened to know the answer.
for the DIY or in general, is there an answer for how or if the rhino homes/calibrates? trying to figure out if it is able to self-centre after being powered off for a while, or if it needs to re-run a homing routine to find a limit for X and Y

Leddhedd•2/13/24, 7:51 PM

so i assume that you set min/max for X and Y, and those values are stored, but after a power off and you move the stick unpowered, does it need to home first before use? most of the videos i see of it being powered just go to center, but im assuming the board is remaining powered and it hasnt lost its positional data

LLeddhedd so i assume that you set min/max for X and Y, and those values are stored, but a...

Fierce_Fire•2/13/24, 7:59 PM

Nah I unplug the whole thing days at a time and it's fine

Fierce_Fire•2/13/24, 8:00 PM

Including power

Stryker990•2/13/24, 8:05 PM

@Bird*dog after looking at the website it looks like u have a older version of the pedal mount that they sell would you be able to give me some photos of your mounts i would like to see how they are constructed

LLeddhedd i had a quick question, if anyone happened to know the answer. for the DIY or in...

smitty•2/13/24, 8:06 PM

On power up it reads the absolute single turn encoder position. It uses the previously stored min/max as the axis limits.

Leddhedd•2/13/24, 8:13 PM

oh okay thats super interesting! is that a physical encoder being turned, or part of the servo control stuff on the back of the motor?

SStryker990 @Bird*dog after looking at the website it looks like u have a older version of t...

Bird*dog•2/13/24, 8:18 PM

Yeah no problem, I’ll DM you

LLeddhedd oh okay thats super interesting! is that a physical encoder being turned, or par...

smitty•2/13/24, 8:32 PM

It’s on the back of the motor

Leddhedd•2/13/24, 8:38 PM

ah okay, so how did that accommodate for multiple motor rotations?

Leddhedd•2/13/24, 8:38 PM

or is this just a right encoder for the job kinda thing

Leddhedd•2/13/24, 8:43 PM

im sure i remember @walmis posting about this not being a problem a while back when i got my kit, im aware there are "single throw" absolute encoders that can rotate multiple times as part of their entire throw, but i think i remember it being a software fix or something

LLeddhedd ah okay, so how did that accommodate for multiple motor rotations?

Fierce_Fire•2/13/24, 9:28 PM

If your system allows multiple rotations you should make sure it's within the correct rotation upon startup(ie if one rotation is 10° movement it should be within 5° either side of the center)

smitty•2/13/24, 10:02 PM

Yea that’s why I size the gear or belt ratio to use just short of 1 full motor rotation

VPforceBot•2/14/24, 9:42 AM

:package:

RHINO #0400 Has Shipped!

Knuck👨✈OP•2/14/24, 9:45 AM

Just finishing up the order form @walmis, do you know if the VP Force mounting plate fits the Rhino FFB base? Thinking the plate might fit the NLR sim seat I have. Thanks again.

KKnuck👨✈Just finishing up the order form @walmis, do you know if the VP Force mounting p...

walmis•2/14/24, 9:49 AM

The plate is specifically designed for Rhino

Knuck👨✈OP•2/14/24, 9:57 AM

Thought so, thank you mate, order form filled out!

TripRodriguez•2/14/24, 2:09 PM

Hey guys, I'm about to 3D print my throw limiters (found in the knowledge base section) and was wondering, what is the native maximum throw in degrees for the Rhino?

AndyHill•2/14/24, 2:24 PM

22 I think

VPforceBot•2/14/24, 2:40 PM

:package:

RHINO #0401 Has Shipped!

AAndyHill 22 I think

TripRodriguez•2/14/24, 3:07 PM

Thanks. Ideally I wanted 21 aft, and since the default on the limiters was 20 I wanted to make sure 21 was ok.

Carlos NO2•2/14/24, 3:08 PM

I love popping in here and seeing more and more Rhinos shipping out. It’s like a rolling Christmas for other people.

TripRodriguez•2/14/24, 3:11 PM

Also, @walmis I just want to say thank you for finally giving us a good force feedback stick that blows the MS FFB2 out of the water in every way possible. I've got #0022 and I absolutely love it.

TripRodriguez•2/14/24, 3:13 PM

On a different note, I feel sure that the software throw limiter generates substantially heavier pull than DCS aircraft when I set everything to max. Is there a way to get DCS aircraft to truly use the Rhino to it's true potential? I confess I haven't yet read the WIP manual, I'm buried in projects right now.

VPforceBot•2/15/24, 9:08 AM

:package:

RHINO #0402 Has Shipped!

VPforceBot•2/15/24, 10:04 AM

:package:

RHINO #0403 Has Shipped!

MGBDave•2/16/24, 11:44 AM

Does anyone have a recommended MSFS Flying Iron Spitfire TelemFFB profile they would be willing to share?

TTripRodriguez On a different note, I feel sure that the software throw limiter generates subst...

TeufelHunden•2/16/24, 12:21 PM

So you’re saying the stick is not giving enough force or too much? I’m just curious.

Rogue Dragon•2/16/24, 4:03 PM

What's current lead time for 57BLF03 motors?

RRogue Dragon What's current lead time for 57BLF03 motors?

Fierce_Fire•2/16/24, 4:10 PM

Motor kit is like a few days, think I had confirmation of sending like a day after purchase

FFierce_Fire Motor kit is like a few days, think I had confirmation of sending like a day aft...

Rogue Dragon•2/16/24, 4:12 PM

And as long as I follow a guide like this I should be fine, right? https://github.com/Gadroc/vpforce-ffb-joystick?tab=readme-ov-file

GitHub

GitHub - Gadroc/vpforce-ffb-joystick: FFB Joystick designed around ...

FFB Joystick designed around VPForceControl kits. Contribute to Gadroc/vpforce-ffb-joystick development by creating an account on GitHub.

RRogue Dragon And as long as I follow a guide like this I should be fine, right? https://githu...

Fierce_Fire•2/16/24, 4:51 PM

Fairly likely, I haven't checked/used those but I believe they're pretty complete

Fierce_Fire•2/16/24, 4:51 PM

And there is always this discord for any questions

RRogue Dragon And as long as I follow a guide like this I should be fine, right? https://githu...

FlatSpin•2/16/24, 5:33 PM

If you get stuck, he's here somewheres you can always ping him.
