Everthing was working fine. I've open the case to tighten main gimbal screw and remount. The stick c

Everthing was working fine.
I've open the case to tighten main gimbal screw and remount.
The stick center wasn't correct any longer. So tried a calibration.

But now I'm unable to have motor provide force any longer.
TM warthog buttons works.
I can see stick moves in windows game controller window.

I have try
Reset Firmware defaults.
Auto calibrate.
Master Gain Main 100%
Effects Springs 100%

Everything works, except there is no force, stick can move freely.
Motors have a green light. There is 24V on all pins with screws.
Firware update button cannot be activated even if connected,
may be because FW version is latest one.

I'm lost.
Except return the DIY kit 57BLF03x2 for check I have no idea what to do.

Ppju38 Everthing was working fine. I've open the case to tighten main gimbal screw and ...

walmis•2/4/25, 2:00 PM

Can you post a screenshot of your configuration?

pju38OP•2/4/25, 2:12 PM

Got your answer per email " your global spring gain is currently at 0% - hence no centering spring force will be available",will try this. Thanks

walmis•2/4/25, 2:13 PM

Don't forget to "Store Config" so your configuration doesn't reset after device restart

pju38OP•2/4/25, 2:30 PM

Solved. Thanks.

pju38OP•2/4/25, 6:17 PM

I don't understand how to have a correct center.
1) I turn the pulley to have rawX,rawY belt not installed near to 2048 in Auto calibration
Than apply/store.
2) Mount centering tool. Mount the pulley.
Autocalibration. Apply/store.
And sitck is not center.

Do I have to unscrew the pulley to have stick center (which is impossible for my case,
I need to unmount the motors to have access to pulley tiny screws) at some time ?

With centering tool set as in picture 2, how store 'this is my center' ?

pju38OP•2/4/25, 6:19 PM

walmis•2/4/25, 6:32 PM

You don't have to change anything more physically - your calibration is within 0-4096 bounds, which is good.
Do the auto calibration routine and save the settings.

pju38OP•2/4/25, 7:35 PM

Ok, thanks.
There is no 'store center'.
Center is computed from Xmin/max Ymin/max calibrated.
Correct ?

Ppju38 Ok, thanks. There is no 'store center'. Center is computed from Xmin/max Ymin/ma...

akabosse•2/4/25, 7:50 PM

Yes, correct. You should be able to just press "auto calibrate", read what it says in the box and press OK, move the stick forward, back, left, right, and press the auto calibration button again to exit calibration mode. Then press "store settings" for it to take effect.
Btw, personally I don't see the need of the centering tool but maybe it's me not thinking it through (as long as you are within the one rotation of the motors, at least when connecting/powering on). I didn't use the centering tool when I assembled mine but maybe I'm lucky

Ppju38 Click to see attachment

Number481•2/4/25, 7:58 PM

your stick is sagging from center, most likely due to grip weight and extension offset (can't see what you've got attached in your photos). Also, your pot is assigned to master gain and set to %50, so you're only getting %50 of whatever spring effect strength you have started in the effects tab.

Spring is weakest at center. You should use the Balancing Procedure to counteract the sag caused by the grip. Once you have that satisfactorily configured, I recommend using the "adaptive recentering" feature in the effects tab spring settings.

Bras•2/5/25, 8:43 PM

Hi guys, does anyone has the 3D print model of the threaded insert to attach the grip when I take it out from the Rhino? I need to be taking it out frequently as I have a flight/racing sim setup and would like to have a nice place to keep the grip near the rig once I take it out instead of the floor

Bras•2/5/25, 8:44 PM

Thank you!

SHAFT•2/6/25, 2:20 AM

I’m having issues with telemFFB connecting to DCS. Worked with no issues a few days ago, haven’t changed anything. Any ideas?

BBras Hi guys, does anyone has the 3D print model of the threaded insert to attach th...

Dracks•2/6/25, 6:37 AM

I'm a little stress this morning but you'll find this 3d file in this discord (sub DIY normally). Walmis had linked theses files here

BBras Hi guys, does anyone has the 3D print model of the threaded insert to attach th...

kaltokri•2/6/25, 8:25 AM

Do you search this? I'm not sure if I understand you question.
https://discord.com/channels/965234441511383080/1198547200058347670/1198547200058347670

BBras Hi guys, does anyone has the 3D print model of the threaded insert to attach th...

Blackrat•2/6/25, 8:43 AM

https://virpil-controls.eu/vpc-grip-stand.html something like this but 3d printed?

Grip Stand

★ Weighted display stand
★ Proudly display your VIRPIL grip collection
★ Aviation inspired design
★ Compatible with all VIRPIL grips

Kkaltokri Do you search this? I'm not sure if I understand you question. https://discord.c...

Bras•2/6/25, 9:15 AM

This is exactly what I need, thanks @kaltokri !!

BBlackrat https://virpil-controls.eu/vpc-grip-stand.html something like this but 3d printe...

Bras•2/6/25, 9:16 AM

Nice solution, already "printed" as well, thanks @Blackrat !

BBras Nice solution, already "printed" as well, thanks @Blackrat !

Fr4Ged•2/6/25, 9:42 AM

There also is a metal variant of that adapter which I would get if I would take the thing off a lot

Bras•2/6/25, 9:57 AM

I did ordered that one with my Rhino, seems like it came mounted in the Rhino already

Mike T•2/6/25, 10:27 AM

Quick support question regards the VPF shift register…….connected to VPF control board as per schematic provided on this Discord…..and checked with DIMM that connections are sound and correct.
Will it work, that is button presses register in the VP Configurator app if board is only powered by USB……..motors not yet connected with power…….i thought the board itself is powered by USB 5v and so therefore the shift register should work…..right?

FFr4Ged There also is a metal variant of that adapter which I would get if I would take ...

Blackrat•2/6/25, 11:03 AM

I got the metal one anyway for longevity. plus I may swap between VKB and TM warthog.

MMike T Quick support question regards the VPF shift register…….connected to VPF control...

TheAmazinGreat•2/6/25, 11:52 AM

Yes, USB connection should be all you need to see button presses.

TeufelHunden•2/6/25, 2:29 PM

TeufelHunden•2/6/25, 2:30 PM

my belt got loose so I tighten it up but I was a dummy and didn't hit the E stop before taking belt off so now I had to re calibrate every single profile I had... I see this number is now RED is this a bad thing?

TeufelHunden•2/6/25, 2:31 PM

it is suppose to be around 2048 right how do I fix?

TTeufelHunden it is suppose to be around 2048 right how do I fix?

TheAmazinGreat•2/6/25, 2:39 PM

Red number means you have a calibration value outside 0..4096. If you turned on your base with the stick in the negative X region it would not find proper center and would lock itself to one side. To fix it you would need to take the belt off, manually set the calibration range 0..4096, then put the belt back on with your stick centered.

TheAmazinGreat•2/6/25, 2:40 PM

And then recalibrate

TTheAmazinGreat And then recalibrate

TeufelHunden•2/6/25, 2:47 PM

thank you so much that worked!

TTheAmazinGreat Yes, USB connection should be all you need to see button presses.

Mike T•2/6/25, 9:32 PM

Thanks…..I guess I need to check the wiring again……none show up, indicating a ground issue but I’ve checked continuity and it’s fine……mmmmm
I wired it up as per pic attached. Selected VP shift register as the grip selection……switches to ground on Shift register and to each of the 32 input positions, but nothing …….is there something else I have to enable?

Mike T•2/7/25, 3:40 AM

MMike T Click to see attachment

TheAmazinGreat•2/7/25, 3:51 AM

Button wiring is the issue. Each of those 4 pins are buttons. They connect to the ground from the VPF main board. So in your pic you have
yellow/yellow/yellow/black

but in reality it’s

yellow/yellow/yellow/yellow to separate GND

TheAmazinGreat•2/7/25, 3:52 AM

If that makes sense

TheAmazinGreat•2/7/25, 3:58 AM

sorry for the crude drawing

TTheAmazinGreat Button wiring is the issue. Each of those 4 pins are buttons. They connect to th...

Mike T•2/7/25, 4:07 AM

Actually as per your pic is how it’s wired…….the pic I posted was from a pic I downloaded from somewhere else on this discord to help with how the connection between shift register and VP control board. My switches are all connected to ground in series and the other side of switches to respective input on Shift register sequentially. So if there is no other requirement to do, it must be either board faulty or I’ve connected something wrong???

Mike T•2/7/25, 4:10 AM

TheAmazinGreat•2/7/25, 4:14 AM

On the 6 pin input connector I see 5 wires which is correct but it looks like they are in positions 1-5? Hard to tell so maybe not but are you sure that is all correct? Looks like it’s missing GND but maybe that’s on the screw terminal?

TheAmazinGreat•2/7/25, 4:16 AM

It looks like DI is connected for some reason.

TheAmazinGreat•2/7/25, 4:16 AM

Maybe I see a GND wire hiding back there.

Mike T•2/7/25, 4:32 AM

Here is a better pic……D1 is wired but goes nowhere as not used…..D0 goes to D1 on VPF board. I’ll recheck connection between boards again.

MMike T Here is a better pic……D1 is wired but goes nowhere as not used…..D0 goes to D1 o...

TheAmazinGreat•2/7/25, 11:47 AM

Ok I see it. If the buttons are as the drawing I posted and board to board is correct it has to be an issue with the grounding or the board to board connections. This might be a dumb question but is the GND used for buttons connected to the same GND used for the board to board connection?

TheAmazinGreat•2/7/25, 11:47 AM

A pic of the configurator debug tab with the debug grip option selected may help troubleshoot also.

NIKO_BG•2/7/25, 1:19 PM

My natural damping compensation value is set at 20%, that way I feal stick moving without any resistance. Is it normal such high value providing that the default is 4%( I am using 86bl04 engines)?

NNIKO_BG My natural damping compensation value is set at 20%, that way I feal stick movin...

smitty•2/7/25, 1:34 PM

if that's what it takes, nothing wrong with that. tune to your hardware, not everyone elses.

NIKO_BG•2/7/25, 1:45 PM

wolfman59#6013•2/7/25, 4:16 PM

hello everyone,
can you confirm to me that there will be no risks, because I am about to connect my rhino VPforce for the first time, with my meanwell 360w 16A only to power my rhino for the moment?
Commentaires

Chris•2/7/25, 6:10 PM

https://tenor.com/view/doja-cat-star-wars-gif-25078126

Tenor

GettinBetter•2/7/25, 6:59 PM

@walmis I've just ordered another pair of motors from yourselves, and a spare FFB circuit board, is it possible that you could add to the invoice and include a spare USB connector cable and PCB plug?

Wwolfman59#6013 hello everyone, can you confirm to me that there will be no risks, because I am...

Blackrat•2/7/25, 7:34 PM

I have a 350w 14A meanwell with the rhino hooked up at 8amps and the rhino MFG at 4 amps, my understanding is that the device will only draw the amps it needs.

Blackrat•2/7/25, 7:35 PM

But there is always a risk whenever you hook power up
